| Brake tester/Test lane Max. drive-over load (t) |
4 |
| Brake tester Roller coefficient dry / wet |
> 0.7 - > 0.6 |
| Brake tester Temperature range (°C) |
0 - 40 |
| Brake tester Idling speed (km/h) |
5.4 |
| Brake tester Roller diameter (mm) |
216 |
| Brake tester Roller length (mm) |
700 / 1000 |
| Brake tester Test width min. (mm) |
800 |
| Brake tester Test width max. (mm) |
2200 |
| Brake tester Length (mm) |
670 |
| Brake tester Width (mm) |
2350 / 2950 |
| Brake tester Height (mm) |
255 |
| Brake tester Weight (kg) |
400 |
| Brake tester Power supply (V/Hz) |
3/N/PE 400 VAC 50 Hz |
| Brake tester Supply lead (mm²) |
5 x 2.5 |
| Brake tester Fuse rating, slow-blow (A slow-blow) |
3 x 25 |
| Brake tester Motor power (kW) |
2 x 3.7 |
| Display cabinet Measuring range (kN) |
0 - 8 |
| Display cabinet Width (mm) |
700 |
| Display cabinet Depth (mm) |
200 |
| Display cabinet Height (mm) |
400 |
| Display cabinet Weight (kg) |
35 |
| Display cabinet Length of line (m) |
15 |
